High speed visual counting packing equipment manufacturer.
1 Years
| Ask Lasest Price | |
| Brand Name : | DGAX |
| Model Number : | DenT |
| Certification : | CE |
| Price : | Contact Us |
| Payment Terms : | T/T |
| Supply Ability : | 100sets/month |
| Delivery Time : | 45-60days |
The difference between visual inspection machines and manual
inspection
Adaptability to working environment
Visual inspection machines
Visual inspection machines can adapt to relatively harsh working
environments to a certain extent, such as high temperature, high
humidity, dust and other environments. However, in extremely harsh
environments, special protection of the equipment or corresponding
environmental control measures may be required.
It can continue to work normally through appropriate optical
protection and heat dissipation measures, etc. Of course, different
visual inspection machines have different adaptability to the
environment.
Manual inspection
Manual inspection has relatively high requirements for the working
environment. In an environment with high temperature, high humidity
or a lot of dust, the work efficiency and inspection quality of the
inspectors will be greatly affected, and working in such an
environment for a long time will also cause harm to the health of
the inspectors.
Working Principle of WirT- Single glass table visual inspection machine
Surface control system
Consists of two workstations mounted above and below the glass plate, each containing a high precision colour camera and a fixed focus lens.
Has an independently digitally adjustable colour illumination system to optimise the image taking.
The main function is to detect cosmetic defects on the upper and lower surfaces.
Inner and outer surface control systems
Consists of outer side workstastions, each with four 2 megapixel colour cameras distributed at 90 degree angles. Each camera uses a low distortion lens. A further feature os that there are two colour lighting systems distributed above and below.
The lighting system can be adjusted digitally and independently to optimise the photographic image.
For the detection of surface defects on the outer side of the product.
Wirt is an optical inspection device specially developed to detect dimensional and surface defects in silicone waterproof plugs. It is capable of inspecting waterproof plugs of various shapes with high precision within its inspection range. These products are inspectied for defects by a series of inspection stations using high-precision industrial cameras. The images obtained by the cameras are transmitted without data loss or interference to a computer managed by a real-time system for image processing: through the operator interface, the user can interact with the operating system in a simple and intuitive way. The detection system is stable, reliable and efficient.
After image processing, objects are imported into three different storage areas for conforming, dimensionally defective and cosmetically defective objects according to the preset inspection criteria. The object inspection parameters are quick and easy to set, the equipment and the feeding device are easy to clean, and the inspection frequency is high.
| Technical parameters | 12 |
| Materials | Silica gel |
| Colour | Full colour |
| Minimum outer diameter(mm) | 3mm |
| Maximum outer diameter(mm) | 12mm |
| Minimum detectable thickness(mm) | 2mm |
| Maximum detectable thickness(mm) | 12mm |
| efficiency | Maximum speed 1000pcs/min depends on product surface and size. |
| Feeding | Vibratory feeding |
| Size Detection | 12 |
| Camera | B/W |
| Detection range(mm) | Φ18 |
| Maximum Detection height(mm) | 12mm |
| Resolution ratio(mm) | 0.001 |
| Detection accuracy(mm) | +/-0.008 |
| Repeated accuracy(mm) | +/-0.005 |
| Height Measurement Inspection | 12 |
| Detection range(mm) | 12mm |
| Resolution ratio(mm) | 0.001 |
| Detection accuracy(mm) | +/-0.008 |
| Repeated accuracy(mm) | +/-0.005 |
| Surface Workstation | 12 |
| Camera | Full colour |
| Individual camera detection range (mm) | 12mm |
| Optical resolution (mm/px) | 0.010 |
| Minimum detectable defect area (mm) | 0.030x0.030 |
| Inner side inspection station (optional) | 12 |
| Camera | Full colour |
| Individual camera detection range (mm) | 12mm |
| Optical resolution (mm/px) | 0.010 |
| Minimum detectable defect area (mm) | 0.030x0.030 |
| Outer Side Inspection Station | 12 |
| Camera | Full colour |
| Individual camera detection range (mm) | 12 |
| Optical resolution (mm/px) | 0.012 |
| Minimum detectable defect area (mm) | 0.036x0.036 |
| optional |
| 5L Hopper |
| 15L Hopper |
| Dust Hood |
| Manual cleaning control |
| Packaging Machine |
Application of DenT- Double glass table visual inspection machine
Electronic components, precision injection molding, hardware fasteners,
sealing rings,rubber silicone,industrial silver contacts, etc.
|
|
